Description
This 24x24x4 meter steel structure offers a reliable, high-quality solution for commercial, industrial, and residential applications. Fabricated to precision, the steel frame, metal sheets, and accessories are designed to withstand the rigors of time and heavy use.
With a comprehensive package including H beams, purlins, roof and wall metal sheets, roller shutter doors, and more, this steel structure is the ideal choice for a wide range of construction and storage projects.
Key Features
-
✅ Main Steel Frame (H Beams) – High-strength, shot-blasted, and primed for durability
-
✅ Galvanized Purlins – Corrosion-resistant for long-lasting protection
-
✅ Single Metal Sheets for Roof & Wall – Standard 0.5mm thickness for solid coverage
-
✅ Electric Roller Shutter Door – Convenient 3m x 3m entry point
-
✅ High-Quality Bolts & Anchor Bolts – Secure assembly with high-strength M20, M16, M12 bolts
-
✅ Comprehensive Accessories Package – Includes screws, rivets, and silicone
Specifications Table
| Specification | Details |
|---|---|
| Steel Frame (H Beams) | 16.02 tons |
| Purlins | C180×2.0mm galvanized |
| Roof Metal Sheets | 630 m² |
| Wall Metal Sheets | 478 m² |
| Roller Shutter Door (Electric) | 3m x 3m |
| Personal Door | 0.9m x 2.1m |
| Aluminum Window | 0.9m x 1.2m |
| Anchor Bolt | M24×850mm |
| High-Strength Bolts | M20, M16, M12 |
Get a Quote Today – We can customise your order to fit your exact needs! Contact us for more details or to get a personalised quote for your project.
